2U PA Stereo Amplifier Outdoor Analog Audio Amplifier 2 channel , 1000 Watt at 4 ohms
Features:
Very compact dimensions
Independent and switchable clipping controller could effectively reduce the distortion and protect the speaker.
Large current dual-toroidal transformer provide flexible load choice, could drive lowest impedance as 2ohms, and with lower noise.
The gain control in front panel has 1dB stepping to achieve quick and accurate volume adjustment.
Each channel has independent DC, over heat and over load protection to protect the amp and speakers automatically.
Description:
T series professional amplifier has high reliability, high performance and high cost performance. With leading circuit technology, the amp could drive any advanced speaker easily. Excellent circuit design, perfect protection and convenient connection and operation, with the powerful and quick power supply, the amp could ensure perfect working with large dynamic.
T series professional amplifier is especially suitable for entertainment and show etc., and got high praise in the market. For middle power application, 2U model could provide power of 400W to 800W each channel at 8 ohms.
Apply to: Entertainment, Performance, Hall
Specification:
| Model | T60 |
| Output Power | |
| Stereo 8Ω | 2x600W |
| Stereo 4Ω | 2x1000W |
| Stereo 2Ω | 2x1500W |
| Bridge 8Ω | 1800W |
| Frequency Response | 20Hz-20KHz (±0.5dB) |
| Input Sensitivity | 0.77V/1V/1.4V |
| THD+N | ＜0.02(rated power, 4Ω, 1KHz) |
| Input Impedance | 10KΩ Balanced/20KΩ Unbalanced |
| Damping Factor | ＞400 |
| S/N Ratio | ＞98dB |
| Input Connector | XLR |
| Output Connector | Binding Post + SPEAKON |
| Protection | soft start, short, over heat, DC, limiter, mute start |
| Dimensions | (485x460x88mm)2U |
| Gross Weight | 26kg |
| Power Supply | AC 210V-240V/50Hz-60Hz |
